BolySolar CSP P2-110
ELECTRICAL PARAMETER(STC)
Unit
Value
Maximum Power
Pmaks(Wp)
107W
Positive Output Tolerance
Watt
0 ~ +0.5W
Max. Power Voltage
Vmpp (V)
17.6V(Preliminary)
Max. Power Current
Impp (A)
6.08A
Open Circuit Voltage
Voc (V)
20.17V
Short Circuit Current
Isc (A)
6.32A
Module Efficiency
ηm(%)
28.75%
MECHANICAL COMPONENTS
Cell Type
Monocrystalline Perc Cell / 11.37mm x 91 mm and 22.74mm x 91 mm
Cell Amount
105 cell (15X7) and 56 cell (8X7)
Panel Size
716mm × 610mm × 41mm
Weight
5.2Kg
Glass
2mm Low Ironed High-Pass Tempered Glass
Frame
Fireproof Composite Tile
Impact Resistance
Decreased from “51.19 / 1300 mm, (1.18 lbs / 535g) Steel Ball Test
